IMS P50VE Press brake
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | France |
| Category: | Hydraulic Presses |
| Manufacturer: | IMS |
| Model: | P50VE |
| Description: | technical characteristics |Power 50 T |between table 355 mm |Stroke from 0 to 80 mm |Size of the lower table 680 x 420 mm |Dimension of the slide 300 x 200 mm |Size of the hole in the slide 40 x 65 mm |Size of the hole in the table 130 mm |Cadence 145 cps / mn |Motor power 3 kW |
| Technical Specifications: | Power in tons: 50 T Table length: 680.0 mm Table width: 420.0 mm Type: Mechanical Ram stroke: 80.0 mm Nbr of strokes/min: 145.0 Distance between columns: 355.0 mm Motor power: 3.0 kW Length x width x height: 1200.0 mm × 1200.0 mm × 2400.0 mm Weight: 2300.0 kg State: good At local norms: --------- Status: visible |
