Smg Pressen Feintoole HFA 6000 metal press
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Russia |
| Category: | Hydraulic Presses |
| Manufacturer: | SMG |
| Model: | Feintoole HFA 6000 |
| Year of Make: | 1989 |
| Description: | Our company, as a proprietor, is ready to supply you with a press hydraulic Faitoole. |The press is intended for finishing. |Technical documentation is. |The kit includes an unwinding device for straightening the metal and a tooling for stamps.|Technical characteristics of the press:|Press model HFA 630 / |year of production 1989 |Plate thickness: 16 mm |slider: |total nominal force: 630 |min. stroke: 30 mm |stroke: 150 mm |cutting speed, min .: 3 mm / s |cutting speed, max .: 50 mm / s |approach speed: 120 mm / s |return speed: 135 mm / s |V-ring: |nominal force: 320 |stroke: 40 mm |Reverse slider: |nominal force: 160 |stroke: 40 mm|DIMENSIONS OF ACCESSORIES: |bottom table - width: 910 mm |bottom table - depth: 1350 mm |top table - width: 900 mm |top table - depth: 900 mm |clearance, max .: 410 mm |Belt feeder: |type: roller feeder: |nominal force: 6000 kN |leaf width, max: 450 mm |sheet thickness, max: 16 mm |feed step, min .: 1 mm|If you are interested |
| Technical Specifications: | Power in tons: 600 T Table width: 910.0 mm Type: Hydraulic Length x width x height: - × - × - Weight: - State: good At local norms: --------- Status: visible |
