Müller CAZ 200 Hydraulic 200 t Press
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Germany |
| Category: | Hydraulic Presses |
| Manufacturer: | Müller |
| Model: | CAZ 200 |
| Year of Make: | 1967 |
| Description: | Machine has a technical defect.|On sale as is. Price negotiable. 4 presses available.|Technical Details: |- pressure: 200 t |- stroke: 500 mm |- throat: 420 mm |- daylight dimension with clamping plate slide/ up: 720 mm |- daylight dimension with clamping plate slide/ low: 220 mm |- table surface area: 1050 x 800 mm |- die cushion hydr. pressure/stroke: 63t / 120mm |- clamping plate on table: 1030 x 800 x 100 mm |- surface area of ram: 1030x630 mm |- total power requirement: 59 kW |- weight of the machine: approx. 22 t |- space requirements of the machine: approx. L:2,77 x B:1,48 x H:4,72 m |- dimensions electric cabinet LxWxH: approx. 1,5x0,5x2,3 m |
| Technical Specifications: | Power in tons: 200 T Table length: 1050.0 mm Table width: 800.0 mm Type: Hydraulic Ram stroke: 500.0 mm Motor power: 59.0 kW Length x width x height: 2770.0 mm × 1480.0 mm × 4720.0 mm Weight: 22000.0 kg State: good At local norms: --------- Status: visible |
