Microcut Femco Metalworker 110/R2 Table type boring machine CNC
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | France |
| Category: | Table Type Boring Mills |
| Manufacturer: | Microcut |
| Model: | Metalworker 110/R2 |
| Year of Make: | 2008 |
| Description: | Brand: MICROCUT FEMCO |Type: Metalworker 110 / R2 |Year: 2008 |Control: Fanuc 21i |Technical characteristics : |- X-axis race: 2,000. mm |- Y-axis race: 1 800. mm |- Z-axis race: 1,700. mm |- Race Axis W:. 550. mm |- Indexation of the spindle: 0.001 degrees |- Spindle cone:. SK 50 |- Rotation speed: 35 - 2,500. rev / min |- Power: 26/22 kW |- Work feed X / Y / Z:. 5,000 mm / min |- Fast feeds X / Y / Z:. 10/10/10 m / min |- Fast forward W / B:. 6/4 m / min |- Rotation Axis B: 11. rev / min |- Overall dimensions: 7.83 x 6.2 x 3.8. m|Equipment: |- Chip conveyor |- Vertical head with watering |- Linear scale |
| Technical Specifications: | CNC: Fanuc 21i X travel: 2000.0 mm Y travel: 1800.0 mm Z travel: 1700.0 mm Max. spindle speed: 2500 rpm Spindle motor power: 26.0 kW Overhauled: no Length x width x height: 7830.0 mm × 6200.0 mm × 3800.0 mm Weight: - State: good At local norms: --------- |
