ABUS GM5200H06-161.41.103.DQA Crane
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Germany |
| Category: | Gantry Cranes |
| Manufacturer: | Abus |
| Model: | GM5200H06-161.41.103.DQA |
| Year of Make: | 2000 |
| Description: | Load hook: |- double hook; mount 100mm; Secure by rope on both sides|Trolley wheels: |- 4 pieces; 200mm; 2 wheel flanges 14mm; wheel tread 58mm|Without operating panel|Technical Details: |- lifting capacity 20,0 t |- span width no bridge - keine Brcke mm |- travel of hook 10 000 mm |- stroke speed 20,0 / 5,0 (Katze) m/min |- stroke speed 4,0 / 0,66 (Hubwerk) m/min |- protection class IP 55 / IP 54 |- rope diameter 14 mm |- track width center 1600 mm |- distance of axis 1500 mm |- total power requirement 0,65 / 0,14 + 15,1 / 2,4 kW |- weight of the machine ca. 1,7 t |- space requirements of the machine approx.: 2,1 x 2,0 x 0,8 m |
| Technical Specifications: | Load Capacity max: 20 T Length x width x height: 2100.0 mm × 2000.0 mm × 800.0 mm Weight: 1700.0 kg State: good At local norms: --------- Status: visible |
