Junker JUPITER 500 Cylindrical centreless grinding machine
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Germany |
| Category: | Centerless Grinders |
| Manufacturer: | Jupiter |
| Model: | JUPITER 500 |
| Year of Make: | 2015 |
| Description: | Technical Details |grinding diameter max. 220 mm |regulating wheel width 500 mm |max. width of grinding wheel 500 mm |Control SIN840D |min. workpiece diameter 3,00 mm |workpiece length - max. 495 mm |grinding wheel diameter max. 440 mm |grinding wheel hole diameter 304,8 mm |power capacity - grinding motor 51,00 kW |peripheral speed 45 / 120 m/sec |grinding head adjustment X1: 160 mm |regulating wheel diameter max. 350 mm |regulated disc boring 203,20 mm |drive control wheel 11,50 kW |regulating-spindle adjustment 220 mm |regulating wheel turning speeds 1 - 800 U/min |regulating-spindle swiveling B2: -015" -- +1 |regulating-spindle tilting C2: -6 -- +6 |total power requirement 85,00 kW |weight of the machine ca. 25,00 t |dimensions of the machine ca. 15,00 x 5,00 x H6,00 m|Centerless grinding machine with SIEMENS Sinumerik 840D control, |loading and unloading unit, dust-exhauster. |Axes: |X1 - Infeed of the wheelhead |X2 - Infeed of the c |
| Technical Specifications: | Max. length of workpiece: 495.0 mm CNC: Yes Type of CNC: Sinumerik 840D Grinding wheel diameter: 440.0 mm Grinding wheel width: 500.0 mm Grinding wheel bore: 304.8 mm Grinding wheel speed: 800 rpm Length x width x height: 15000.0 mm × 5000.0 mm × 6000.0 mm Weight: 25000.0 kg State: good At local norms: --------- Status: visible |
