Pfauter P251 Vertical gear hobbing machine
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Germany |
| Category: | Hobbing Machines |
| Manufacturer: | Gleason-Pfauter |
| Model: | P251 |
| Description: | Cutter diameter 130 mm |Cutter width - max. 160 mm |Adjustability of the milling spindle 115 mm |Milling carriage swiveling 240 degrees |Feed: 2|Change gears, |arbors, |Clamping tables, |Table mandrels |Chip conveyor, |Coolant system |manuals|Table bore diameter 63 mm |Milling mandrels 22, 27, 32 |Table diameter 250 mm |Distance milling spindle - clamping spindle max. 210 mm |Distance milling spindle - clamping spindle min. 10 mm |Number of teeth - min. 6 |Milling width max. 245 mm |Machining diameter max. 250 mm |Base area 625x1720 mm |Cutter spindle speeds 1.) 96-320 rpm |Milling spindle speeds 2.) 120-400 rpm |
| Technical Specifications: | Max wheel Ø: 250.0 mm Module +: 6.0 Module -: 1.0 Max spindle speed: 400 rpm Max gear width: 210.0 mm Motor power: 18.0 kW Length x width x height: 3700.0 mm × 2200.0 mm × 2500.0 mm Weight: 4000.0 kg State: good At local norms: --------- Status: under power |
