Lathe ZMM C10 TM
$ 59,389
| Type: | Buy-It-Now |
| Location: | Austria | Wiener Neudorf | Niederösterreich |
| Category: | Lathes |
| Manufacturer: | ZMM Metalik |
| Model: | C 10 TM |
| Description: | Center height: 380 mm Turning diameter over bed: 760 mm Turning diameter over cross slide: 520 mm Turning diameter in the offset: 950 mm Bed width: 560 mm Distance between centers: 3,000 mm Spindle mount / DIN55027: No. 11 Spindle bore: 132 mm Spindle taper: M 140 Speeds: 7,5 - 1,015 rpm. (17) Main engine: 11/15 kW Feed number: 150 Longitudinal feed: 0.039 - 18 mm / rev Cross feed: 0.02 - 9 mm / rev Thread Count: Metric (76): 0.5-180 mm Customs (76): 60 - 1/6 gears / " Module (76): 0.125 - 45 DP (76): 240 - 2/3 Adjustment range cross slide: 410 mm Adjustment range upper slide: 150 mm Tailstock Pinole Diameter: 105 mm Tailstock recording: MK 6 Tailstock Pinolenweg: 225 mm Weight: 4,470 kg |
HESSE+CO Maschinenfabrik GesmbH Industriezentrum NÖ-Süd, Straße 4, Objekt 8A-2351 Wiener NeudorfAustria | |
