Top turning machine ZMM C 10 TMS
$ 65,503
| Type: | Buy-It-Now |
| Location: | Austria | Wiener Neudorf | Niederösterreich |
| Category: | Lathes |
| Manufacturer: | ZMM Metalik |
| Model: | C 10 TMS |
| Description: | Center height: 380 mm Turning diameter over bed: 760 mm Turning diameter over cross slide: 520 mm Turning diameter in the offset: 950 mm Bed width: 560 mm Distance between centers: 3,000 mm Spindle mount / DIN55027: No. 11 Spindle bore: 132 mm Spindle taper: M 140 Speeds (variable with 3 levels): 7 - 42; 28-170; 165 - 1,015 rpm Main engine: 15 kW Feed number: 150 Longitudinal feed: 0.039 - 18 mm / rev Cross feed: 0.02 - 9 mm / rev Thread Count: Metric (76): 0.5-180 mm Customs (76): 60 - 1/6 gears / " Module (76): 0.125 - 45 DP (76): 240 - 2/3 Adjustment range cross slide: 410 mm Adjustment range upper slide: 150 mm Tailstock Pinole Diameter: 105 mm Tailstock recording: MK 6 Tailstock Pinolenweg: 225 mm Weight: 4,470 kg |
