Machining Center - Vertical made in Taiwan SVL-1200
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Germany | Erwitte |
| Category: | Vertical Machining Centers |
| Manufacturer: | YOU JI |
| Model: | SVL-1200 |
| Description: | Factory new vertical machining center Country Taiwan Type SVL-1200 with CNC contouring control Mitsubishi M70-2A, or other hardened and precision linear guides on all 3 axes. SPECIFICATIONS Table size 1400 x 610 mm Travel X, Y, Z 1200 x 600 x 600 mm distance table - spindle nose 120-720 mm distance stand -. Spindle nose 680 mm Max table load 800/1000 kg Engine power spindle motor 7.5 / 11.0 KW / optional 11 / 15 kW output axis motors X, Y, Z 2.0 / 2.0 / 2.0 KW / 2.0 / 2.0 / 3.5 KW tool holder BT 40 spindle speed 60-8000 U / min feed range 1 - 10000 mm / min rapid traverse in X, Y, Z 30/30 / 24 m / min tool changer 20 times / optional 24 Maximum tool diameter 75 mm machine weight 7000/7500 kg equipment STANDARD ACCESSORIES transformer for 380 volt precision linear guides in all axis CE conformity tapping without compensating chuck color monitor 8.4 inch LCD / MDI air through the spindle Preloaded precision ballscrews in all 3 axes RS 232 cabinet air conditioner chip conveyor screw shape |
