Machining Center - Vertical made in Taiwan SV-1800
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Germany | Erwitte |
| Category: | Vertical Machining Centers |
| Manufacturer: | YOU JI |
| Model: | SV-1800 |
| Description: | Factory new vertical machining center Country Taiwan Type SV-1800 with CNC contouring control Mitsubishi M70-2A, with hardened precision flat guides in 3 axes. SPECIFICATIONS Table size 1900 x 900 mm Travel X, Y, Z 1800 x 950 x 750/900 mm optional distance table? Spindle nose 200? 950 mm / 200 optional? 1100 mm distance stand? Spindle nose 1030 mm Max table load 2500 kg Engine power spindle motor 15 / 18.5 optional kW output axis motors X, Y, Z 3.5 / 3.5 / 3.5 KW Tool fixture BT-50 Spindle speed 60 -. 6000 U / min feed range 1? 7 m / min rapid traverse in X, Y, Z 15/15/12 m / min tool changer 24 times / optional 32 Maximum tool diameter 125 mm Weight 16000 kg FEATURES AND STANDARD EQUIPMENT transformer for other voltage 4 Boxways in the Y axis CE conformity threading without compensating chuck 8.4 inch LCD / MDI air through the spindle Preloaded precision ballscrews in all 3 axes Hardened precision flat guides in all axes for high cutting RS 232 cabinet air conditioner chip conveyor sc |
